In short: instead of repeating recurring building-block substructures, factor those out into a crosscutting concepts.

Troublesome redundancy

See the following building block diagrams: The top-level (whitebox X) consists of blackboxes A, B and D - which are refined in three diagrams.

All those refinements look strikingly similar - that’s too much redundancy.

building blocks diagram with too much redundancy

Crosscutting Concepts to the rescue

A somewhat leaner approach, based upon crosscutting concepts, avoids this redundancy. In the following diagram, the whitebox contains blackboxes A, B and D - but there’s no refinement for those. Instead, they all carry the stereotype «X-service», refering to a crosscutting concept that explains how elements of type X-service» shall be constructed, build or implemented.

building blocks diagram, leaner approach

Crosscutting concepts might describe principles, rules or implementation restrictions that must hold for specific kinds of building blocks. See section 8 for details.

  • Explain concepts instead of too many building block details, see tip 5-28.
  • You should name important concepts, and use these names in building blocks, see tip 8-11.
